DURA-GRIP Parallel Grippers PH Series
PH-5
	Miniature two finger parallel gripping head 0.125" [3.1mm] Max stroke Weight – 0.09 lb [0.04 kg] CAD library / Catalog Pages / PDF Print
PH-10
	Miniature two finger parallel gripping head 0.187" [4.7mm] Max stroke Weight – 0.15 lb [0.07 kg] CAD library / Catalog Pages / PDF Print
PH-20
	"Stack-Pack" Grip Head, narrow profile parallel gripper. This allows close center distance mounting for multiple head stacking, as required in racking/deracking, palletizing/depalletizing and other similar applications. Adjustable finger opening and closing stops, top male dovetail mounts, and front or side mounting holes. Weight - 4.6 oz Max Stroke- .250" CAD library / Catalog Pages / PDF Print
PH-30
	Mini two finger parallel gripping head 0.250" Max stroke 1.50" x 0.937" rectangular body Top male dovetail mount. Dovetail perpendicular with fingers Weight - 5 oz CAD library / Catalog Pages / PDF Print
PH-31 Optional flat top (no dovetail) CAD library / Catalog Pages / PDF Print
PH-40
	Mini two finger parallel gripping head 0.250" Max stroke Top male dovetail mount. Dovetail inline with fingers 1.5" Diameter Body Weight - 6 oz CAD library / Catalog Pages / PDF Print
PH-41 Optional flat top (no dovetail) CAD library / Catalog Pages / PDF Print
PH-50
	Small two finger parallel gripping head 0.40" Max stroke Top male dovetail mount. Dovetail inline with fingers 2" Diameter Body Weight - 13 oz CAD library / Catalog Pages / PDF Print
PH-51 Optional flat top (no dovetail) CAD library / Catalog Pages / PDF Print
PH-60
	Small two finger parallel gripping head 0.52" Max stroke Top male dovetail mount. Dovetail inline with fingers 2" Diameter Body Weight - 14 oz CAD library / Catalog Pages / PDF Print
PH-61 Optional flat top (no dovetail) CAD library / Catalog Pages / PDF Print
PH-70
	Large two finger parallel gripping head 1.000" Max stroke Top male dovetail mount. Dovetail inline with fingers 2 ½" Diameter Body Weight - 1-¾ lbs CAD library / Catalog Pages / PDF Print
PH-71 Optional flat top (no dovetail) CAD library / Catalog Pages / PDF Print
